First Use

  1. Unboxing
  2. Charging the OVR Nodes
  3. Install & Run OVR Portal 2
  4. Suit up the straps, number, and type of the straps you receive depends on the product you bought, as below:
    • WalkOVR One comes with 1 chest (long) strap + 1 OVR Node
    • WalkOVR Twins comes with 2 legs (short) strap + 2 OVR Node

    • WalkOVR Trio comes with 2 legs and 1 chest strap + 3 OVR Node

    • WalkOVR Pro comes with 4 legs and 1 chest strap + 5 OVR Node

Adsiz

Node positioning for Locomotion at left side, OVR Node positioning for Mocap at right side



  1. Place the OVR Nodes (WalkOVR One / Twins / Trio)
  2. Turn on OVR Nodes
    • Turn on OVR Nodes by clicking the power button on devices

NOTE: After turning on the OVR Node, you can connect directly through the OVR Portal. On the contrary, in the WalkOVR Classic version, you don’t need to pair your WalkOVR through Windows Bluetooth settings.

  1. Install & Run OVR Portal 2
  2. Login to OVR Portal 2
  3. Choose New WalkOVRs and a play mode when the OVR Portal is opened
    • Go to Settings, then Devices, and choose new WalkOVR
    • Go to Motion Profiles, then Play Mode, and choose locomotion or mocap mode
  4. Click the Search&Connect button at Connection Status window
    motionprofile 1
  5. You should see the OVR Nodes are connected by green color, then click the “calibrate nodes” button and complete the calibration process by following the instructions in the steps “calibrate nodes”, “manage node positions”, and “reset posture” sequentially.
  6. If you selected locomotion mode, walk in place and bend your body to various directions to monitor if everything is working properly by following the arrows and the avatar on the Connection Status window.
  7. If you selected locomotion mode, set Motion Profile settings to set the precision on your movement
  •
